Type TTon charterIn the current daily production process, there are detailed operating specifications. Specifically, the operation process is based on six steps. Now let the editor take you into the operation process of the ton bag packaging machine.
1. Preparation before packaging
The empty tray is manually placed on the packaging position under the weighing platform.
Two, bagging (manual)
The operator presses the "set" button, the elevator frame automatically lowers to the set position, the operator hangs the bag on the hooks of the four packaging machines, then puts the bag inlet into the packaging machine, and then clicks the start button, and the bag clamping device automatically The bag is clamped, and the bag is clamped by the filling mouth of the packaging, so that it is in a completely sealed state, and the manual setting is automatically lifted, which is suitable for this kind of bag packaging position.
Three, peel (automatic)
The packaging machine automatically strips out the packaging weight.
Four, fast feeding (automatic)
The packaging machine automatically opens the gravity feed mechanism and starts rapid feed. At the same time, the packaging machine automatically opens the suction valve to achieve negative pressure dust removal. During the feeding process, the weighing instrument continuously detects the weight of the materials in the packaging bag. When the weight of the material in the packaging bag reaches the manually set fast feeding amount, the fast feeding is completed.
Five, slow feeding (automatic)
After fast feeding, the packaging machine automatically switches to slow feeding. When the weight of the slow feed material is equal to the quantitative value, the feeding process ends, and the packaging machine automatically stops feeding and closes the cut-off door.
Six, unloading the bag
After the charging process of the ton charter machine is over, the four bag hanging cylinders make the bag hooks automatically release the belt, the bag equipment automatically opens, relaxes the imported packaging bag, and the vacuum valve automatically closes, delays for a period of time, and then the material bag is on the pallet. The operator presses the button to start the chain conveyor bag transport package position, which is the forklift pallet.
